Digital Proface HMI Touch Screen GP37W2-BG41-24V Graphic Panel LCD Display 24V 20W 5.7 Inch New
Overview
Model 2880052-01 or GP37W2-BG41-24V, as listed by Pro-face, has a rated voltage level of DC 20.4V to DC 27.6V. The panel consumes 20W or less. The insulation resistance is 20Mohms or higher at DC 500V (between charging and FG terminals), and the voltage endurance between the charging and FG terminals is AC 1000V 10mA for one minute. The allowable voltage drop is 2ms or less. The GP37W2-BG41-24V has an electrostatic discharge immunity of 6kV (complies with IEC 61000-4-2 Level 3).
This specific panel has a Blue mode monochrome LCD, with eight levels of adjustment for contrast that are available through the touch panel. The touch panel is a resistive film with one or two-point touch and 16x12 keys/screen.
The atmospheric pressure the GP37W2-BG41-24V can function is 800 to 1114hPa (2000meters or lower). The air purity level for the panel is less than 0.1mg/m3 of conductive dust, with an ambient humidity of 20%RH to 85%RH with no condensation. The atmosphere needs to be free of any corrosive gasses. The grounding needed for the panel is 100ohms or less or your country's applicable standard. The front face of the installed unit is rated as the equivalent to IP65f (JEM 1030), and NEMA#250 TYPE4x12. The main unit weighs 1.1kg {2.4lb} or less. The cooling method for this unit is natural air circulation. The external dimensions for the main unit are W 207 [8.17] x H157 [6.18] x D58 [2.28] mm [in]. Refer to Pro-face's instruction manuals to install this panel and review safety protocol.
Product Details
| Brand | Proface |
| Product | HMI Touch Screen |
| Model |
GP37W2-BG41-24V |
| Type |
2880052-01 |
| Specifications |
Display Color :Blue Mode Display Type: Monochrome LCD Resolution:320 x 240 pixels Screen Size:5.7 inches Series:GP37W2 Nominal Display Area (mm):115.2(W) × 86.4(H) Display Attributes:Blink/ Reverse Video Contrast Control:8 levels of adjustment available via touch panel Application Memory:1MB FLASH EPROM (holds up to 320 screens, assuming an average screen size of 3.2 KB) Data Backup Memory: 96KB SRAM *1 Touch Panel:16 × 12 keys per screen; 1 or 2 point touch |
| Weight | 2KG |
| Warranty | One Year |
| Other Touch Screen |
GP37W2-BG41-24V GP37W3-BG41-24V GP3W2-BG41 GP377-SC41-24V GP370-LG11-24V GP270-LG11-24V GP270-SC11-24V GP370-SC11-24V GP377-LG11-24V GP377-LG41-24V GP377-SC11-24V GP377-SC41-24V GP2301-LG41-24V GP2300-LG41-24V GP2300-SC41-24V GP2300-TC41-24V GP2301-SC41-24V GP2301-TC41-24V GP2400-TC41-24V GP2401-TC41-24V GP2500-TC11 GP2500-TC41-24V GP2500-LG41-24V GP2500-SC41-24V GP2501-SC41-24V GP2501-LG41-24V GP2501-TC11 GLC2600-TC41-24V GLC2500-TC41-24V GP2501-TC41-24V GP2501-SC11 GP2600-TC11 GP2601-TC11 GP2600-TC41-24V GP2601-TC41-24V GP2500-TC41-24V-M FP2600-T12 GLC2500-TC41-200V GLC2600-TC41-200V GP4105G1D GP4104G1D GP4601G1D GP4501TADW GP4501TAA GP4501TAD GP4501TADWGP4 If you need other models, pls feel free to contact us. |
| More |
PFXGP4501TAD PFXGP4501TAA PFXGP4601TAA PFXGP4601TAD PFXGP4601TMA PFXGP4203TAD PFXGP4201TADW PFXGP4201TAD PFXGP4402WADW PFXGP4502WADW PFXGP4301TADW PFXGP4301TAD PFXGM4301TAD PFXGP4402WADW PFXGP4502WADW PFXGC4401WAD PFXGE4501WAD PFXGP4402WADW PFXGE4501WAD PFXGP4401WADW PFXGP4502WADW |
Dimensions
