AB Allen-Bradley Bulletin 1492 Termination Module PLC Input Output Module 1492-TIFM40F-24-2 Terminal Block New
Overview
Allen-Bradley 1492-TIFM40F-24-2 is 40-Point Fusible Digital Termination Module for 1746/1756 I/O Systems.
The Allen-Bradley 1492-TIFM40F-24-2 is a 40-point fusible digital termination module from the 1492 wiring system. It supports 24V AC/DC operation, with 2A per circuit and 12A per module maximum current. Equipped with fuse clips, LED indicators, and fixed terminal blocks, it enables easy wiring and error reduction, compatible with 1746/1756 series I/O modules. Certified for Class I, Div. 2 hazardous areas, it's ideal for industrial automation signal termination.
Application Notes
1. Compatibility — To ensure proper operation with the I/O module, do not exceed the voltage and current ratings of the IFM. When this IFM is used with a hard contact (relay) output circuit that switches an inductive load, surge suppression must be used (e.g., a 1N4004 diode reverse-wired across a DC load).
2.Wiring — Refer to the Label Section on page174. For Field-Side Wiring Diagrams, refer to the Wiring System web site information on page200.
3. Fusing — Fuse holders are included with the IFM. Fuses (5x 20mm) are not included.
4. Isolation — The power bus, fuse clips, and blown fuse indicators are isolated into four groups of 10terminals (eight fuse clips and blown fuse indicators). This allows each group of output devices to reference a different power source.
Product Details
Wiring configuration: 2-wireSeries:1492 Wiring System
1492-IFM20F
If you need other models, pls feel free to contact us.
Brand:
AB
Type:
Termination Module
Model
1492-TIFM40F-24-2
Specifications
Product Type :40-Point Fusible Digital Termination Module
Operating Voltage:24V AC/DC (10-30V AC/DC range)
Current Rating:2A per circuit, 12A per module
I/O Points:40 Points
Terminal Block Type:Fixed Terminal Block
Key Features:Fuse clips, LED indicators, easy wiring, minimal setup errors
Compatibility:1746 Series, 1756 Series, 1771 Series I/O Modules
Installation Areas :Class I, Div. 2 Hazardous Locations, Safe Areas
Operating Temperature:Up to 60°C (T3C Temperature Code)
Country of Origin
Mexico
Weight
2 KG
