SIEMENS Pushbutton 3SU1150-0AB40-1FA0 Screw terminal 1NO 1NC 22MM Green Button

Description

SIEMENS Pushbutton 3SU1150-0AB40-1FA0 Screw terminal 1NO 1NC  22MM Green Button

---

Product Details

Brand	SIEMENS
Article Number (Market Facing Number)	3SU1150-0AB40-1FA0
Product Description	Pushbutton, 22 mm, round, metal, shiny, green, pushbutton, flat, momentary contact type, 1 NO+1 NC, screw terminal
Encl.Type:	1,2,3,3R,4,4X,12
Weight without packaging	0.5 kg

---

Manufacturer's article number

1 of supplied contact module 3SU1400-1AA10-1FA0
of supplied LED module 3SU1401-1BC40-1AA0
of the supplied holder 3SU1550-0AA10-0AA0
of the supplied actuator 3SU1051-0AB40-0AA0

Number of LED modules: 1

Number of command points: 1

Actuator

Design of the operating mechanism: Button, flat
Manner of function of the actuating element: momentary contact type
Product extension optional Light source: Yes
Color of the actuating element: green
Material of the actuating element: plastic
Shape of the actuating element: round
Outer diameter of the actuating element: 29.45 mm
Number of contact modules: 1

Front ring

Product component front ring :Yes
Design of the front ring: Standard
Material of the front ring: Metal, high gloss
Color of the front ring: silver

Holder

Material of the holder: Metal

Display

Number of LED modules: 1

---
