Honeywell SmartLine Gauge Pressure Transmitter STG77L-E1G000-1-A-AHC-11C-B-11A0-F1-0000 New

Description

Honeywell SmartLine Gauge Pressure Transmitter STG77L-E1G000-1-A-AHC-11C-B-11A0-F1-0000 New

Overview

Honeywell STG77L SmartLine Gauge Pressure transmitter
Part of the SmartLine family of products, the STG700 andSTG70L are suitable for monitoring, control and data acquisition. STG70X products feature piezoresistive sensor technology combining pressure sensing with on chip temperature compensation capabilities providing high accuracy, stability and performance over a wide range of application pressures and temperatures.The SmartLine family is also fully  tested and compliant with Experion PKS providing the highest level of compatibility assurance and integratio capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.

Accuracy up to 0.065 % of calibrated span
Stability up to 0.02% of URL per year for five years
Automatic temperature compensation
Rangeability up to 100:1
Response times as fast as 100ms
Alphanumeric display capabilities
External zero, span, & configuration capability
Polarity insensitive electrical connections
On-board diagnostic capabilities
Integral Dual Seal design for safety based on
ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
Full compliance to SIL 2/3 requirements as a standard.
Modular design characteristics
