AB Allen Bradley ControlLogix 5580 GuardLogix Controller 1756-L81E Processor with 3MB Memory New
Overview
The ControlLogix controller provides a scalable controller solution that is capable of addressing many I/O points. You can place the ControlLogix controller into any slot of a ControlLogix I/O chassis, and install multiple controllers in the same chassis.
ControlLogix controllers can monitor and control I/O across the ControlLogix backplane, and over network links. The ControlLogix 5580 controllers have an embedded Ethernet port for a direct connection to Ethernet-enabled devices and networks, and also support communication interface modules in the local chassis. To provide communication for ControlLogix 5570 or ControlLogix 5560 controllers, install the appropriate communication interface module into the local chassis.
ControlLogix 5580 and ControlLogix 5570 controllers are available with a conformal coating. A conformal coating provides a layer of protection against contaminants and humidity to help protect the assembly and extend product life in harsh, corrosive environments. Products with a conformal coating have a ‘K’ suffix at the end of the catalog number.
The Allen-Bradley 1756 ControlLogix controllers provide a robust and scalable control solution for industrial automation systems. A standard control engine with a development
environment provides ease of use. Available with On-Machine models suitable for process, motion, discrete, and highavailability applications.
The 1756-L81E from Rockwell Automation is a ControlLogix 5580 controller with 3 MB user memory and a USB port. It has a 1 Gb Ethernet port and four character alpha / numeric display. And it is for 100 Ethernet / IP devices.
Details
1756-L72EROM, 1756-L73EROM
1756-L72EROMS, 1756-L73EROMS
1756-CN2, 1756-CN2R, 1756-CNB, 1756-CNBR, 1756-DNB, 1756-DHRIO, 1756-DH485, 1756-EN2F, 1756-EN2T, 1756-EN2TP, 1756-EN2TR, 1756-EN3TR,
1756-EN4TR, 1756-ENBT, 1756-EWEB, 1756-RIO, 1756-SYNCH, 1756-TIME,1756-CN2RK, 1756-EN2FK, 1756-EN2TK, 1756-EN2TPK, 1756-EN2TRK, 1756-EN4TRK, 1756-ENBTK, 1756-TIMEK,1756-CN2RXT, 1756-DHRIOXT, 1756-EN2TPXT, 1756-EN2TXT, 1756-EN2TRXT, 1756-EN4TRXT,1756-IA8D, 1756-IA16, 1756-IA16I, 1756-IA32, 1756-IB16, 1756-IB16D, 1756-IB16I, 1756-IB16IF,1756-IB32, 1756-IC16, 1756-IG16, 1756-IH16I, 1756-IM16I, 1756-IN16, 1756-IV16, 1756-IV32, 1756-OA8, 1756-OA8D,1756-OA8E, 1756-OA16, 1756-OA16I, 1756-OB8, 1756-OB8EI, 1756-OB8I, 1756-OB16D, 1756-OB16E, 1756-OB16I,1756-OB16IEF, 1756-OB16IEFS, 1756-OB16IS, 1756-OB32, 1756-OC8, 1756-OG16, 1756-OH8I, 1756-ON8, 1756-OV16E,
Brand
AB
Product
ControlLogix 5580 Controller
Model
1756-L81E
Condition
New
Specifications
Supply voltage DC:5.1 V
Voltage type of supply voltage:DC
Number of HW-interfaces USB:1.0
Can be programmed with Connected Components Workbench: No
Can be programmed with Studio 5000 Logix Designer:Yes
Can be programmed with RSLogix 500: No
Supporting protocol for EtherNet/IP:Yes
Memory size:3000.0 kByte
Suitable for safety functions:Yes
Model；Modular
With display：Yes
Rail mounting possible：No
Wall mounting/direct mounting：No
Rack-assembly possible：Yes
Catalog Numbers
ControlLogix Controller Catalog Numbers:
1756-L61, 1756-L62, 1756-L63, 1756-L63XT, 1756-L64, 1756-L65,1756-L71, 1756-L72, 1756-L73, 1756-L73XT, 1756-L74, 1756-L75,1756-L71K, 1756-L72K, 1756-L73K, 1756-L74K, 1756-L75K,1756-L81E, 1756-L82E, 1756-L83E, 1756-L84E, 1756-L85E,1756-L81EK, 1756-L82EK, 1756-L83EK, 1756-L84EK, 1756-L85EK
GuardLogix Controller Catalog Numbers:
1756-L61S, 1756-L62S, 1756-L63S, 1756-LSP,1756-L71S, 1756-L71SK, 1756-L72S, 1756-L72SK, 1756-L73S, 1756-L73SK, 1756-L7SP, 1756-L7SPK, 1756-L73SXT, 1756-L7SPXT,1756-L81ES, 1756-L81ESK, 1756-L82ES,1756-L82ESK, 1756-L83ES, 1756-L83ESK, 1756-L84ES, 1756-L84ESK, 1756-L8SP, 1756-L8SPK
Armor ControlLogix Catalog Numbers:
1756-RM2, 1756-RM2XT
Other 1756 Products
1756-OV32E, 1756-OW16I, 1756-OX8I
1756 ControlLogix I/O Modules
|
AC Digital Catalog Numbers |
1756-IA8D, 1756-IA16, 1756-IA16K, 1756-IA16I, 1756-IA16IK, 1756-IA32, 1756-IA32K, 1756-IM16I, 1756-IM16IK, 1756-IN16, 1756-OA8, 1756-OA8D, 1756-OA8E, 1756-OA16, 1756-OA16K, 1756-OA16I, 1756-OA16IK, 1756-ON8 |
|
DC Digital Catalog Numbers |
1756-IB16, 1756-IB16K, 1756-IB16D, 1756-IB16DK, 1756-IB16I, 1756-IB16IK, 1756-IB16IF, 1756-IB16IFK, 1756-IB16ISOE, 1756-IB16ISOEK, 1756-IB32, 1756-IB32K, 1756-IC16, 1756-IG16, 1756-IH16I, 1756-IH16ISOE, 1756-IV16, 1756-IV16K, 1756-IV32, 1756-IV32K, 1756-OB8, 1756-OB8EI, 1756-OB8I, 1756-OB16D, 1756-OB16DK, 1756-OB16E, 1756-OB16EK, 1756-OB16I, 1756-OB16IEF, 1756-OB16IEFK, 1756-OB16IEFS, 1756-OB16IS, 1756-OB32, 1756-OB32K, 1756-OC8, 1756-OG16, 1756-OH8I, 1756-OV16E, 1756-OV32E |
|
Safety Catalog Numbers |
1756-IB16S, 1756-OBV8S |
|
Contact Catalog Numbers |
1756-OW16I, 1756-OX8I |
|
Analog Catalog Numbers |
1756-IF6CIS, 1756-IF6I, 1756-IF8, 1756-IF8K, 1756-IF8I, 1756-IF8IK, 1756-IF16, 1756-IF16K, 1756-IF4FXOF2F, 1756-IF4FXOF2FK, 1756-IR6I, 1756-IRT8I, 1756-IRT8IK, 1756-IR12, 1756-IR12K, 1756-IT6I, 1756-IT6I2, 1756-IT16, 1756-IT16K, 1756-OF4, 1756-OF4K, 1756-OF6CI, 1756-OF6VI, 1756-OF8, 1756-OF8K, 1756-OF8I, 1756-OF8IK |
|
HART Interface Catalog Numbers |
1756-IF8H, 1756-IF8HK, 1756-IF8IH, 1756-IF8IHK, 1756-IF16H, 1756-IF16HK, 1756-IF16IH, 1756-IF16IHK, 1756-OF8H, 1756-OF8HK, 1756-OF8IH, 1756-OF8IHK |
|
Specialty Catalog Numbers |
1756-CFM, 1756-CMS1B1, 1756-CMS1C1, 1756-HSC, 1756-LSC8XIB8I, 1756-LSC8XIB8IK, 1756-PLS |
Wiring Diagrams of ControlLogix DC (10...31.2V) output module 1756-OB32
Types of 1756 Removable Terminal Blocks
|
Attribute |
1756-TBNH |
1756-TBSH |
1756-TBCH |
1756-TBS6H |
1756-TBE |
|
Description |
20-position NEMA screw-clamp removable block |
20-pin spring-clamp removable terminal block with standard housing |
36-pin cage-clamp removable terminal block with standard housing |
36-pin spring-clamp removable terminal block with standard housing |
Extended depth terminal block housing |
|
Screw torque |
0.8…1 N.m 7…9 lb.in |
0.8…1 N.m 7…9 lb.in |
0.4 N.m 4.4 lb.in |
0.4 N.m 4.4 lb.in |
- |
The list of Analog Input Modules with Removable Terminal Block
| Models of Analog Input Module | Models of Removable Terminal Block |
|
1756-IF6CIS |
1756-TBNH 1756-TBSH |
|
1756-IF6I |
1756-TBNH 1756-TBSH |
|
1756-IF8H |
1756-TBCH 1756-TBS6H |
|
1756-IF8 |
1756-TBCH 1756-TBS6H |
|
1756-IF8I |
1756-TBCH 1756-TBS6H |
|
1756-IF8IH |
1756-TBCH 1756-TBS6H |
|
1756-IF16 |
1756-TBCH 1756-TBS6H |
|
1756-IF16H |
1756-TBCH 1756-TBS6H |
Analog RTD and Thermocouple Modules
Models of Analog Module
Models of Removable Terminal Block
1756-IR6I
1756-TBNH
1756-TBSH
1756-IRT8I
1756-TBCH
1756-TBS6H
1756-IT6I
1756-TBNH
1756-TBSH
1756-IT6I2
1756-TBNH
1756-TBSH
Analog Output Modules
| Models of Analog Output Modules |
Models of Removable Terminal Block |
|
1756-OF4 |
1756-TBNH 1756-TBSH |
|
1756-OF6CI |
1756-TBNH 1756-TBSH |
|
1756-OF6VI |
1756-TBNH 1756-TBSH |
|
1756-OF8 |
1756-TBNH 1756-TBSH |
|
1756-OF8H |
1756-TBNH 1756-TBSH |
|
1756-OF8I |
1756-TBCH 1756-TBS6H |
|
1756-OF8IH |
1756-TBCH 1756-TBS6H |
Analog Combination Input and Output Module
|
Models of Analog Combination Input and Output Module |
Models of Removable Terminal Block |
|
1756-IF4FXOF2F |
1756-TBCH 1756-TBS6H |
Specialty I/O Modules
| Models of Specialty I/O Modules |
Models of Removable Terminal Block |
|
1756-CFM |
1756-TBNH 1756-TBSH |
|
1756-HSC |
1756-TBCH 1756-TBS6H |
|
1756-LSC8XIB8I |
1756-TBCH 1756-TBS6H |
|
1756-PLS |
Requires 3 RTBs: 1756-TBNH or 1756-TBSH |
