Home Products More Products Others SICK S300 Series Safety Laser Scanner S3
SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  1. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  2. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  3. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  4. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  5. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  6. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  7. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New
  8. SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New

SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New

SICK Scanners  , Sick Safety Laser Scanner  , Sick Security Laser Scanners
Send Inquiry Live chat

Description

SICK S300 Series Safety Laser Scanner S30B-3011GB Indoor Security Laser Electronic Scanners 1057641 New


Overview

SICK At A GlAnCe
SICK is one of the leading manufacturers of intelligent sensors and sensor solutions for industrial applications. A unique range of products and services creates the perfect basis for controlling processes securely and efficiently, protecting individuals from accidents and preventing damage to the environment. We have extensive experience in a wide range of industries and understand their processes and requirements. With intelligent sensors, we can deliver exactly what our customers need. In application centers in Europe, Asia and North America, system solutions are tested and optimized in accordance with customer specifications. All this makes us a reliable supplier and development partner.
Comprehensive services complete our offering: SICK lifetime Services provide support throughout the machine life cycle and ensure safety and productivity.
For us, that is “Sensor Intelligence.”

S300 passes the baton to nanoScan3: After many years of successful use in countless industries, the S300 safety laser scanner is now handing over the baton to its successor, nanoScan3.

nanoScan3 is the smallest safety laser scanner from SICK and is ideal for the protection and localization of mobile platforms. Thanks to the reliable safeHDDM® scanning technology.

it delivers high-precision measurement data and is extremely resistant to light, dust or dirt. With smart connection technology, a scanning angle of 275°,

a rugged design and a comprehensive portfolio, the nanoScan3 also offers the right successor product for your application.


Features
Up to 3 m protective field range
270° scanning angle
Up to 48 freely configurable fields and 16 switchable field sets
Configuration memory integrated into the system plug
EFI interface for safe SICK device communication
Configuration using the CDS software


Product Details

Brand SICK
Type Safety Laser Scanner
Model S30B-3011GB
Order Code 1057641
Technical Information
Product version:S300 Expert
Model:Sensor without system plug
Application:Indoor
Protective field range:3 m
Warning field range:8 m (at 15 % reflectivity)
Distance measuring range:30 m
Type of field set:Triple field sets
Number of field sets:16
Number of fields:48
Number of monitoring cases:32
Scanning angle:270°
Resolution (can be configured):30 mm, 40 mm, 50 mm, 70 mm, 150 mm
Angular resolution:0.5°
Response time:80 ms
Protective field supplement:100 mm
Number of multiple samplings:2 ... 16, configurable
Delay of automatic reset:2 s ... 60 s, configurable
Mechanics
Dimensions (W x H x D):102 mm x 152 mm x 106 mm
Housing material:Aluminum die cast
Housing color:RAL 1021 (yellow)
Optics cover material:Polycarbonate
Optics cover surface finish:Outside with scratch-resistant coating
Net Weight 2KG
Warranty One Year
Country of Origin Germany
Sick Laser Scanner 1056430 S32B-3011BA
1051884 S32B-2011EA
1050932 S32B-2011BA
1058000 S32B-0011BA
1028934 S30A-4011BA
1028935 S30A-4011CA
1045650 S30A-4111CP
1045652 S30A-6111CP
1052593 S30A-6111CL
1023546 S30A-6011BA
1023548 S30A-6011EA
1023891 S30A-7011CA
1023891 S30A-7011BA
2026802  S30A-XXXXCA
1026820 S30B-2011BA

1056428 S30B-3011CA

1026821 S30B-2011CA
1026822 S30B-2011DA
1026821 S30B-2011GA
1026821 S30B-3011DA
1057641 S30B-3011GB
1056427 S30B-3011BA
1028936 S30A-4011DA

S30BS100
RLY3-S300 1099973
If you have any need on SICK products,pls feel free to contact us.
Sick Encoder
ATM60-A4M12X12 1030004
ATM60-D4H13X13 1030017
ATM60-A4A12X12 1030001
ATM90-AXA0-S01 1033057
ATM60-PAH13X13 1030015
ATM60 P4H13X13 1030013
ATM60-D1H13X13 1030018
ATM60-C1H13X13 1030025
ATM60-A4K12X12 1030002
AD-ATM60-KA3PR 2029225
ATM60-AAK12X12 1030010
ATM60-A4A12X12 1030001
ATM60-A1A0-K20  1034295
ATM60-AAK12X12
ATM60-P1H13X13
ATM60-D4H13X13
ATM60-D1H13X13
ATM90-AXA0-S01
BTF08-A1AM0340
AD-ATM60-SR2DN
AD-ATM60-KR1DN
AD-ATM60-KR2DN
AD-ATM60-KA3PR
AD-ATM60-KR3CO
If you have any inquiries of SICK products, pls feel free to contact us.


Dimensional drawing Laser scanner
