Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor
  1. Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor
  2. Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor
  3. Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor
  4. Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor

Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor

Yaskawa omron ac motors  , Sigma II series servo motor  , 200W industrial servomotor
Send Inquiry Live chat

Description

Yaskawa Sigma II Servomotor SGMAH-02AAA61D-OY OMRON 200W Servo Motor




Description of SGMAH-02AAA61D-OY


Model SGMAH-02AAA61D-OY is a Motors-AC Servo produced by Yaskawa
Servomotor Type
SIGMA II SGMAH Series
Rated Output
200W (0.25hp)
Power Supply
200V
Encoder Specifications
Steel Encoder ,13-bit (2048 x 4) Incremental Encoder
Shaft Specifications
Straight without keyway
Design rank
Standard
Speed 3000rpm
Similar Motors SGMAH-01AAA61D-OY
SGMAH-02AAA61D-OY
SGMAH-03AAA61D-OY
SGMAH-04AAA61D-OY
SGMAH-07AAA61D-OY
SGMAH-08AAA61D-OY
SGMAH-01AAA6SD-OY
SGMAH-02AAA6SD-OY
SGMAH-03AAA6SD-OY
SGMAH-04AAA6SD-OY
SGMAH-07AAA6SD-OY
SGMAH-08AAA6SD-OY



About SGMAH Sigma II


3,000 RPM to 5,000 RPM (Max Speed)

The SGMAH servomotor series is a legacy product and is no longer promoted in the Americas. It had a low-inertia design for extremely fast accelerations and short settling times. There were five frame sizes including NEMA 23 and NEMA 34 flanges providing up to 1,010 oz-in of peak torque.


About AC Servomotor


AC servomotors are divided into two types: synchronous type and induction type. The synchronous type is more commonly used. For a synchronous type servomotor, motor speed is controlled by changing the frequency of alternating current. A synchronous type servomotor provides strong holding torque when stopped, so this type is ideal when precise positioning is required. Use this type for a servo mechanism for position control.

A servomotor must have “instantaneous power” so that it can start as soon as a start reference is received. The term “power rating (kW/s)” is used to represent instantaneous power. It refers to the electric power (kW) that a servomotor generates per second. The greater the power rating, the more powerful the servomotor.

The following figure illustrates the structure of a synchronous type servomotor:

Yaskawa SGM and SGMP Servomotors are of the synchronous type.
